CAN-FAN MAX-FAN ETALINE - 2360m3/h - Ø315mm

Code: 1084
Brand: CAN-FAN
€248,94 €205,74 excl. VAT
On Order
Delivery offer

Controllable using the Satellite 4A + LCD EC fan controller  (NOT INCLUDET!)

DATA SHEET

According to the German standard, the fans are supplied without an electrical plug (only cable with shaved wires). Must be installed before use!

Detailed information

Product detailed description

Max-Fan is a unique diagonal tube fan, designed to be efficient, powerful and less noisy.
The rotor-stator system makes Max-Fan the most efficient fan on the market, taking into consideration both air performance and power consumption.
The rotor pushes the air out in a swirl, while the stator transforms this swirl into an uniform jet of air, preventing pressure loss, noise and unnecessary power consumption.
The efficiency rate for Max-Fan is 50 %, higher than any conventional one propeller tube fan, available on the market today.

Max-Fan one speed is now controllable using Can-Fan Satellite 4A, this combination functions as a speed Controller.
In case you want to have full control, just Plug Can-Fan LCD EC Controller in Can-Fan Satellite 4A and you are ready to go.

As a protection for the motor, it is equipped with a thermal switch, that turns off the motor if it reaches a dangerous working temperature.
In addition, Max-Fan comes with mounting brackets for an easier use.

For efficient performance with the best possible results, we strongly recommend the use of Max-Fan together with Can Filters.

Prefered filters: CAN-Lite 2500, CAN150bft, W/150

Specifications:
Voltage: 230V
Frequency: 50Hz
Max. Current: 1.6A
Noise: 56dB
Power consumption: 270W
Maximum working temperature: 55 ° C
Fan weight: 8.4kg
Flange size: 315mm
Air flow: 2360 m3 / h
