GSE Timer Box IV 12x600W + heating - 400V - 48A

Product detailed description

The Timer BOX 4 has a digital display that is based on a 24 hour mechanical timer. With an encoder button left-right and press, It's an easy way setting the clock even faster than a mechanical timer. 48 segments show the current time and the programmed duration at a glance.

The clock has a 12h or 18h cycle preprogrammed, a user-defined time hours/minutes can be set. The clock has a day counter and a temperature probe for an emergency stop in case of overheating. In addition to the on-off function especially for inductive loads, the Timer Box 4 has a 0-10V or PWM output for dimmable e-ballasts or LED lamps. This signal dims the lamps when the temperature rises, or functions such as sunrise/sunset are possible. When the lamps are switched off, a heating socket is switched on. (Power management). IP54 Protection class offers protection against splashing water from all sides.

Features:

• 1 channel 24h timer

• Green dimmable display

• Designed for inductive loads

• 0-10V or PWM output.

• Temperature display

• Emergency stop temperature monitoring

• Dimming

• Sunrise sunset

• Day counter

• Time format 0-24h or 12 AM/PM

• Temperature format ° C or ° F

• Heating release when the light is off

Technical specifications:
Housing: WxHxD = 200x255x95mm
Timer box: WxHxD = 230x300x110mm
3 pole 3x10A 6'900W
3 pole 3x16A 11'000W CEE16A
Volt: 230V / 50Hz
Protection class: IP54
